Ashok Leyland make water cooled diesel engine model H6ETIC3RS23, 158 hp (118 Kw) @ 2300 rpm or equivalent |
Coupled with engine for coupling 3 pump sets. |
400 TPH |
10 mm (Min) to 300 mm (Max) |
Hydrostatic |
Hydraulic (Sonic sensor system MOBA Germany make for automatic material flow control) |
On three sides of machine |
Solid Rubber Tyre |
Pneumatic Tyre, 4 Nos., Size: 12.00 x 20 – 18 ply. |
Sliding, MOBA make |
Right side |
Left & Right side |
Double operator seats |
Hydrostatic steering for effortless operation. |
Using Simple Switches |
Speed reduction gearbox to achieve low / high speed of pave with differential |
Made from alloy steel and are hardened and ground for efficient working. |
Hydraulic |
6.0 CM |
Dia 375 mm |
12 V DC |
2.75 m basic width, Hydraulically extendable up to 4.9 m, further bolt on extension up to 7.5 m. (vibration, tamping & heating facility up to 7.5 meters) |
LPG Gas Burner (Manually Operated) |
-1° / +4° |
Yes, infinitely variable up to 50.00 Hz (Max.) |
Yes, infinitely variable, 33.33 Hz (Max.) |
Auto & Manual mode, MOBA Matic sensor device, Germany make |
0 to 30 meters/min Max |
0 to 12 km/hr Max |
Fuel: 175 L |
21,265 kg (approx.) |
Closed : 2.39 m (Approx), Open : 3.24 m (Approx) |
7.34 Meter |
Operating: 3.59 m, Shipping: 2.81 m |
1. Canvas Canopy |
Bituminous Only |
BS-III |
Caliper disc brakes on both the side |
Danfoss (Germany make) or equivalent |
